Welded Gabion Mesh Panels Manufacturer & Custom Supplier
We manufacture and export Wire Mesh Panel products for international projects, with production established since 2014. Welded Gabion Mesh Panels are supplied for retaining walls, slope protection, riverbank protection and landscape structures. We produce panels to specified mesh opening, wire diameter, panel dimensions and surface treatment, with custom configurations available for project requirements. Production inspection, export packing and order follow-up support clear specification control from quotation through shipment.
-
![Welded Gabion Erosion Control Units]()
Welded Gabion Erosion Control UnitsWelded Gabion Erosion Control Units are stone-filled structures assembled from welded steel wire mesh panels. Base, side, end and diaphragm panels create defined compartments for controlled stone -
![Welded Gabion Slope Protection Units]()
Welded Gabion Slope Protection UnitsWelded Gabion Slope Protection Units are stone-filled structures assembled from welded steel wire mesh panels. Base, side, end and diaphragm panels form separate compartments for controlled stone -
![Welded Landscape Gabion Boxes]()
Welded Landscape Gabion BoxesWelded Landscape Gabion Boxes are stone-filled units assembled from welded steel wire mesh panels. The panels form the base, side walls, end panels and internal divisions of each unit. They are used -
![Welded Gabion Retaining Walls]()
Welded Gabion Retaining WallsWelded Gabion Retaining Walls are modular stone-filled structures made from welded steel wire mesh panels. Panels form the front, rear, base and side sections, with internal diaphragms dividing each -
![Welded Gabion Baskets]()
Welded Gabion BasketsWelded Gabion Baskets are stone-filled units assembled from welded steel wire mesh panels. The panels form the base, sides, ends, and internal diaphragms, creating defined compartments for stone -
![Welded Gabion Boxes]()
Welded Gabion BoxesWelded Gabion Boxes are rigid stone-filled wire containers manufactured from welded steel mesh panels. The panels form the base, side walls, end panels, and internal diaphragms required to create
Product Advantages
Stable Face Alignment
Welded intersections hold the mesh in a fixed position, helping assembled gabion faces maintain a regular profile during stone filling.
Practical Assembly
Flat panels can be joined at the installation site with specified connection components, allowing the gabion structure to be formed from individual panels.
Technical Specifications
|
Parameter |
Typical Specification |
|
Product Type |
Welded Gabion Mesh Panels |
|
Material |
Low Carbon Steel Wire |
|
Mesh Opening |
50 × 50 mm, 75 × 75 mm, 100 × 100 mm |
|
Wire Diameter |
3.0–6.0 mm |
|
Panel Length |
Custom |
|
Panel Width |
Custom |
|
Surface Treatment |
Hot-Dip Galvanized, Zn-Al Alloy Coated, PVC Coated |
|
Connection |
Spiral Wire, C-Rings, U-Clips |
|
Reinforcement |
Internal Stiffeners |
|
Supply Form |
Flat Panels / Panel Sets |
Hot-Dip Galvanized
A zinc coating provides corrosion protection for outdoor structures and general gabion applications. It is commonly selected where galvanized steel is specified for the project.
Zn-Al Alloy Coated
A zinc-aluminium alloy coating provides an alternative metallic protection system for applications requiring a different coating specification.
PVC Coated
A polymer coating forms an additional outer barrier over the wire surface. It can be selected where the project requires additional surface protection or a defined finished appearance.
Applications
Retaining Walls
Welded gabion panels can be assembled into stone-filled retaining structures for terraces, landscape changes and selected site development projects.
Slope Protection
The panels form modular stone-filled units for slope protection and erosion-control layouts where the specified structure requires a rigid welded mesh configuration.
Riverbank Protection
Stone-filled gabion structures can be used along riverbanks and drainage areas where water movement and ground conditions form part of the project considerations.
Landscape Structures
Common landscape uses include garden walls, planters, partitions and decorative structures where consistent panel geometry is required.
Custom Welded Gabion Panels
Panel Dimensions
Panel length and width can be matched to the required gabion size, installation layout and project drawings.
01
Mesh and Wire Selection
Mesh opening and wire diameter can be specified according to the selected stone size, panel dimensions and structural requirements.
02
Connection Configuration
Spiral wires, C-rings, U-clips and internal stiffeners can be specified according to the required assembly method and panel arrangement.
03
RFQ Review
For quotation, provide mesh opening, wire diameter, panel dimensions, surface treatment, quantity and drawings when available. The information can be reviewed before the production specification is confirmed.
04
Manufacturing & Quality Control
Wire Preparation
Steel wire is prepared to the specified diameter before entering the welded mesh production process.
Panel Processing
Welded panels are processed to the specified dimensions before inspection, surface treatment where required, and packing.
Mesh Welding
Wire intersections are resistance-welded according to the required mesh opening and panel configuration.
Inspection Control
Mesh opening, wire diameter, panel dimensions and visible production conditions are checked against the confirmed order requirements.
Packing & Export Support
Flat Bundle Packing
Panels can be packed flat and bundled for transport, allowing efficient handling during loading, unloading and site storage.
Accessory Packing
Specified spirals, clips, stiffeners and other connection components can be organized with the corresponding panel configuration.
Shipment Coordination
Production progress, packing and shipment arrangements are followed through the order process so that quantities and confirmed specifications remain aligned with the shipment.
Why Choose Us
Established Production
Our manufacturing operation was established in 2014, with Wire Mesh Panel products forming part of the product range supplied to international customers.
Custom Specification
Mesh opening, wire diameter, panel dimensions and related configurations can be reviewed against customer drawings and project requirements.
Quality Management
A quality management system is maintained as part of our production controls, supported by product inspection before shipment and a documented quality management certification.
After-Sales Support
After-sales inquiries and confirmed product quality issues are handled through our service process, including replacement support for confirmed quality defects within the applicable warranty period.
FAQ
Q: What mesh openings are available?
A: Common mesh openings include 50 × 50 mm, 75 × 75 mm and 100 × 100 mm. Other specifications can be reviewed according to the project requirement.
Q: What wire diameters can be supplied?
A: Typical wire diameters are 3.0–6.0 mm. The final diameter should be confirmed according to the panel dimensions and project specification.
Q: Which surface treatment should I select?
A: Hot-dip galvanized, Zn-Al alloy coated and PVC-coated options are available. Selection should consider the service environment, required coating specification and project conditions.
Q: Can the panels be customized?
A: Yes. Panel dimensions, mesh opening, wire diameter, surface treatment and connection configuration can be reviewed from drawings or detailed specifications.
Q: What information is needed for a quotation?
A: Provide the mesh opening, wire diameter, panel dimensions, surface treatment, quantity and project drawings when available. These details allow the required panel configuration to be reviewed before quotation.
Q: How are welded gabion panels packed?
A: Panels are supplied in flat bundles for transportation and handling. Connection components can be organized according to the confirmed panel configuration and shipment requirements.
Request a Welded Gabion Mesh Panel Quote
Send your mesh opening, wire diameter, panel dimensions, surface treatment, quantity and project drawing. We will review the requirements and confirm the production configuration for quotation.
As one of the most professional welded gabion mesh panels manufacturers and suppliers in China, we also support customized service and OEM service. Please feel free to buy high quality welded gabion mesh panels for sale here from our factory. For price consultation, contact us.
