Rolled-Edge Safety Fence

Rolled-Edge Safety Fence is a welded steel mesh panel with continuously formed top and bottom edges. The rolled profile creates a rounded exposed boundary, while welded wire intersections maintain a fixed mesh pattern and panel shape.
The fence is used for schools, parks, public facilities, industrial premises, commercial properties and other perimeter areas where open visibility and controlled panel edges are required. Panel height, width, wire diameter, mesh opening, post section and surface treatment can be specified to suit the fence layout.

Welded Mesh Panel
Horizontal and vertical steel wires are welded at fixed intersections to form a uniform mesh panel.
Rolled Top Edge
The upper wire section is formed into a continuous rounded profile along the panel width.
Rolled Bottom Edge
The lower section follows the same formed profile to maintain consistent panel geometry.
Steel Posts
Posts support the panels and are selected according to panel width, fence height, fixing method and foundation arrangement.

Rounded Panel Edge
The rolled profile reduces exposed straight wire ends along the upper and lower panel boundaries.
Consistent Mesh Grid
Fixed welded intersections maintain the specified mesh opening across the panel.
Open Visibility
The mesh structure allows visual access through the fence while maintaining a defined perimeter line.

Low-Carbon Steel
Low-carbon steel wire is suitable for welded panel production and edge forming.
Galvanized Steel
Galvanized wire or panels provide zinc protection for outdoor fencing applications.
Powder-Coated Finish
A powder-coated layer can be applied over galvanized steel when the project requires a specified color and finished surface.

Fence Height
Typical panel heights range from 1.2 m to 2.4 m. Selection depends on the required boundary level, site layout and access conditions.
Mesh Opening
A 50 × 200 mm opening provides a clear visual field while maintaining defined separation. Other opening sizes can be specified for different project layouts.
Wire Diameter
Common wire diameters are 4.0–6.0 mm. The selected diameter should correspond with panel dimensions, support spacing and required panel rigidity.

Galvanized Layer
Galvanizing provides a zinc coating over the steel surface for outdoor exposure and general atmospheric conditions.
Powder-Coated Layer
Powder coating adds a uniform finished surface and allows the fence color to follow the project specification.
Surface Inspection
Finished panels can be checked for coating coverage, visible surface condition and dimensional consistency before packing.

Post Spacing
Post spacing should correspond with panel width and fixing locations to maintain a continuous fence line.
Panel Fixing
Panels can be secured to compatible posts with clamps, bolts or other mechanical fixing components selected for the post section.
Foundation Method
Posts can be embedded in concrete or installed with base plates where the supporting structure and project design permit.

Public and Pedestrian Areas
Suitable for schools, parks, walkways and public facilities where visibility and a rounded panel edge are required.
Industrial Sites
Used around factories, workshops, storage areas and controlled-access compounds for perimeter separation.
Commercial Properties
Applicable to commercial premises, property boundaries and developed sites requiring an open welded mesh structure.
Infrastructure Areas
Suitable for utility compounds, transport-related facilities and other sites requiring a defined perimeter.

Wire Diameter
Incoming and finished wire diameter can be checked against the specified tolerance before panel production and shipment.
Welded Intersections
Weld points are inspected for secure joining and consistent formation across the mesh panel.
Panel Dimensions
Panel height, width, mesh opening and rolled-edge dimensions are checked against the approved specification.
Surface Finish
Galvanized and powder-coated surfaces are inspected for coverage, adhesion and visible surface condition.

Panel Stacking
Finished panels are stacked and secured to limit movement and contact during handling.
Post Bundling
Posts and fixing components are bundled according to the shipment configuration and installation requirements.
Packing Identification
Labels can include panel dimensions, quantities, post specifications and project reference information for receiving and installation.
