Product Description

The Double Wire Mesh Fence is welded from low-carbon steel wire. The fence has no outer frame. Two reinforced horizontal wires run across the top and bottom. The standard mesh opening is 75mm by 150mm. The panel measures 3000mm wide and 1800mm high. The wire diameter after coating is 4.0mm or 4.5mm. The surface receives hot-dip galvanizing plus PVC dip coating. Standard colors include green, white, and blue.

Product Parameters

Parameter	Specification
Material	Q195, Q235 Low Carbon Steel
Wire Diameter (before coating)	3.0–5.0mm
Wire Diameter (after coating)	3.5–6.0mm
Mesh Opening	75×150mm, 50×100mm, 80×160mm, 90×170mm
Panel Width	1.8m, 2.0m, 2.5m, 3.0m
Panel Height	1.2m, 1.5m, 1.8m, 2.0m, 2.5m
Post Type	Round Φ48mm or square 50×50mm
Post Spacing	3.0m
Surface Treatment	Hot-dip galvanizing + dip coating

Product Advantages

The Double Wire Mesh Fence offers high strength against impact and cutting. Its frameless design makes it lightweight and easy to transport. Hot-dip galvanizing ensures 10+ years of rust protection. The fence adapts well to slopes and uneven ground. This Double Wire Mesh Fence is also an economical choice for large projects.

Main Applications

Livestock farming uses 3.0m by 1.8m panels with 3.5-4.0mm wire. Highway protection requires 4.0-4.5mm wire on 3.0m by 1.5m or 2.0m panels. Heavy industrial zones need 4.5-5.0mm wire. Construction sites prefer roll mesh. Large farms rely on the Double Wire Mesh Fence with 5.0mm+ wire.
