Product Definition
Prison security fence is a high-grade security isolation barrier designed for correctional institutions, primarily composed of Y/V-type support columns, 358 anti-climb, anti-theft connectors, and hot-dip galvanized razor wire. This is engineered to prevent unauthorized intrusion, with a robust structure that resists climbing, shearing, and forced damage. It adheres to national construction standards, ensuring maximum safety for prison premises and personnel.
Product Specification
|
Item |
Details |
|
Core Mesh Type |
358 Anti-climb Dense Mesh (standard configuration) |
|
Mesh Parameters |
Aperture: 76.2mm×12.7mm (3"×0.5"), Wire diameter: 4.0-5.5mm, Material: CDW550 high-grade low-carbon steel wire, Weld tensile strength ≥2000N |
|
Standard Mesh Size |
2.5m-3.0m high × 2.0m-3.0m wide (stackable up to 4m) |
|
Frame Specification 30×50mm/40×40mm square steel, wall thickness ≥2.5mm |
|
|
Column Specification |
60×60mm/80×80mm square tube (Q235B), wall thickness 3.0-4.0mm High-security version: 100×100mm×4.0mm square tube |
|
Top Anti-climb Device |
BTO-22 razor wire (stainless steel/hot-dip galvanized), Diameter 500-600mm (concertina type), Installation height ≥0.5m |
|
Surface Treatment |
Dual anti-corrosion: Hot-dip galvanizing (zinc coating ≥80μm) + Outer layer: Electrostatic spraying/immersion plastic spraying (dark green/grey) |
|
Fixing Method |
Embedded (depth ≥800mm) or Flange plate + Expansion bolts |
|
Compliance Standards |
GA 1025-2012, JGJ 446-2018, Construction Standard 139-2010 |
Product Advantages
1. The prison security fence adopts a 358 anti-climb mesh design with ultra-narrow apertures, making it impossible to grasp or climb, effectively blocking intrusion.
2. Features a dual anti-corrosion process, ensuring a service life of over 15 years (20 years for coastal areas with Teflon coating).
3. Equipped with BTO-22 razor wire and Y/V-type brackets, forming a three-dimensional anti-climb barrier with strong deterrent effect.
4. Uses anti-theft bolts and seamless welding structure, with no protruding points or foot points, preventing damage and climbing.
5. A compact structure, convenient transportation and installation, adapting to various prison site conditions.
Application Scenarios
- Correctional institutions, prisons, and detention centers for perimeter isolation and high-security protection
- Military bases, confidential military sites, and restricted military areas
- High-security government buildings, border checkpoints, and confidential office areas
- Power stations, nuclear facilities, and other key energy supply sites
- High-security warehouses, logistics bases, and important industrial sites
FAQ
Q1: What is the core anti-climb feature of the prison security fence?
A: It uses 358 anti-climb mesh with an aperture of 76.2mm×12.7mm, which is too small for hands or feet to grasp, making climbing impossible. It is matched with BTO-22 razor wire to form a double anti-climb protection.
Q2: How long is the service life of the production?
A: It adopts hot-dip galvanizing + spraying process, with a zinc coating of ≥80μm. Its service life is over 15 years in general areas, and it can reach 20 years in coastal areas with special anti-corrosion treatment.
Q3: Can the production be customized for high-security projects?
A: Yes.It has a high-security version with a total height of ≥4.5m, smaller mesh holes (50mm×50mm), and double-layer spiral razor wire, which meets the higher anti-climb and anti-damage requirements of high-security prisons.
