Product Description
The Chain Link Wire Mesh is woven from Q235 low-carbon steel, high-carbon steel, or stainless steel wire using a mechanical knotted (hooked) process. It features a diamond-shaped opening with no welding points, giving it a flexible yet strong structure. This unique weaving method provides high tensile strength and elongation, allowing the mesh to absorb heavy impacts without falling apart. Whether used for poultry farming, slope protection, or stadium fencing, this Chain Link Wire Mesh offers superior durability and corrosion resistance.
Product Parameters
|
Parameter |
Specification / Range |
|
Material |
Q235 Low Carbon Steel, High Carbon Steel, Stainless Steel (304/316) |
|
Wire Diameter |
1.2mm – 5.0mm (SWG 18# – 7#) • Light duty: 1.8–2.5mm • Medium duty: 2.5–3.5mm • Heavy duty: 3.5–5.0mm |
|
Mesh Opening |
25mm, 40mm, 50mm, 60mm, 65mm, 76mm, 100mm |
|
Roll Width / Height |
0.5m – 5.0m |
|
Roll Length |
15m, 30m, 40m, 50m per roll |
|
Surface Treatment |
Electro-galvanized / Hot-dipped galvanized (60–120g/m²) / PVC coated / Stainless steel |
|
Tensile Strength |
≥ 350 MPa |
|
Elongation |
≥ 15% |
|
PVC Coating Thickness |
0.8 – 1.2 mm |
Main Applications
Agriculture and farming fencing, sports venue protection, highway and railway barriers, slope protection for rivers, community fences, and temporary construction site fencing.
Frequently Asked Questions (FAQ)
Q1: Can you produce custom sizes (height, length, or mesh opening)?
A: Yes. We accept custom orders. Whether you need a 5m high roll, a roll longer than 100m, or a special mesh opening such as 65mm or 76mm, we can manufacture according to your drawings or requirements.
Q2: Will the PVC coating peel off over time?
A: No. Our PVC/PE coating is applied with advanced technology and adheres tightly to the galvanized wire core. It is UV-resistant and anti-aging, and will not crack or peel under normal outdoor use.
